Nordic ID Sampo S1 Long-range RFID reader | NPA00001-EU

Description

Product Description : Nordic ID Sampo S1

The Nordic ID Sampo S1 is a versatile and reliable RFID reader with a USB interface for communication and power. It supports robust RFID functionalities like AES authentication and fast tag processing. Designed for optimal usability, it is suitable for various industries and applications, providing efficient solutions for inventory management, access control, and more.

Key Features

• High RFID Performance: Supports ISO 18000-63 (EPC Class 1 Gen2 V2) with AES authentication.
• Long-Range Reading: Up to 5 meters with integrated antenna, extendable to 7 meters with One-Series.
• External Antenna Ports: Three SMA female ports for flexible antenna configurations.
• Power Options: USB or external AC/DC adapter.
• Durability: IP20-rated for indoor use, operational between -20°C to 55°C.
• User-Friendly Interface: Equipped with LEDs, buzzer, light sensor, and tapping sensor for operational indicators.

Product Quality and Performance

• Speed: Processes up to 200 tags per second in DRM mode.
• Adjustable Power: RFID radiated power adjustable in 1 dB steps, up to +30 dBm (1 W).
• Connectivity: USB 2.0 as a serial port.
• GPIO Options: Opto-isolated inputs and outputs for extended functionality.

Specifications

• Dimensions: 200 x 260 x 25 mm (7.9 x 10.2 x 1.0 inches).
• Weight: 540 grams (19.0 oz).
• Storage Temperature: -40°C to 85°C (-40°F to 185°F).
• Operating Power: 3 W.
• Frequency Bands: ETSI 865.6–867.6 MHz, FCC/IC 902–928 MHz.

Purpose of Use

Ideal for:

• Point-of-sales and access control systems.
• Inventory management and document tracking.
• Tag programming stations and smart shelves.

How to Use

1. Setup: Connect via USB or external power supply.
2. Integration: Configure using Nordic ID RFID Configurator software.
3. Operation: Monitor status using LED indicators or sound alerts.

Supported OS/Application/Industries

• Operating Systems: Windows XP, Vista, 7, 8, 10, Linux, and Android.
• Industries: Retail, logistics, and office management.

Benefits & Compatibility

• Seamlessly integrates with existing systems.
• Wide compatibility with UHF RFID tags and applications.
• Reliable operation with a robust build for indoor use.

Warranty and FAQs

• Warranty: Two years with free technical support during and after the warranty period.
• Service Options: Maintenance and extended contracts, software customization, and project management support.

Best Price Guarantee

The Nordic ID Sampo S1 is competitively priced, ensuring exceptional value for its advanced features and performance.

After Sales Support

Includes free support during the warranty period, software development assistance, and technology consultation services.

Request for Customer Reviews and Testimonials

We welcome user feedback on the Nordic ID Sampo S1 to ensure the best customer experience and continuous improvement.
